PRODUCT DESCRIPTION (English)

The AKT-TGDRX-500W LED Flood Light is a powerful commercial-grade outdoor lighting solution engineered to provide exceptional brightness, durability, and energy efficiency. Delivering an impressive 40,000 lumens with a crisp 6500K daylight color temperature, it is designed to illuminate expansive outdoor environments with consistent, high-quality lighting.

Built with a rugged weather-resistant housing and an IP66 waterproof rating, this floodlight performs reliably under demanding environmental conditions including heavy rain, dust, humidity, and fluctuating temperatures. The premium aluminum heat sink ensures effective heat dissipation for stable operation and extended service life.

Designed for industrial, commercial, municipal, and security lighting projects, the AKT 500W LED Flood Light offers dependable illumination while significantly reducing energy consumption compared to conventional floodlights.

Key Features (English)

  • High-performance 500W LED Flood Light
  • Ultra-bright 40,000 Lumens output
  • Efficient 6500K Daylight White illumination
  • Wide AC input voltage (85–265V)
  • High-quality isolated LED driver
  • IP66 waterproof and dustproof protection
  • Anti-lightning protection
  • Anti-surge technology
  • Excellent heat dissipation with aluminum housing
  • Stable operation in harsh weather conditions
  • Operating temperature: -20°C to 50°C
  • Long service life of approximately 10,000 hours
  • Low maintenance requirements
  • Energy-efficient replacement for traditional floodlights
  • Suitable for large-scale outdoor lighting applications
Parameter Explanation Data
Product Name LED Flood Light AKT LED Flood Light
Model Product Model Number AKT-TGDRX-500W
Product Code Factory Product Code SLEDTGD000048
Power Rated Power Consumption 500W
Luminous Flux Total Brightness Output 40,000 Lumens
Input Voltage Operating Voltage AC85–265V
Frequency Operating Frequency 50–60Hz
Color Temperature Light Color 6500K (Daylight White)
Color Rendering Index (CRI) Color Accuracy ≥70
Dimmable Brightness Adjustment No
Waterproof Rating Dust & Water Protection IP66
Driver Type Power Driver Isolated Driver
Surge Protection Electrical Protection Yes
Lightning Protection Safety Feature Yes
Heat Dissipation Cooling System High-efficiency Aluminum Heat Sink
Operating Temperature Working Environment -20°C to 50°C
Lifespan Expected Service Life 10,000 Hours
Housing Material Construction Material Die-cast Aluminum
Light Source LED Type High-Efficiency LED Chips
Installation Method Mounting Style Adjustable Bracket Mount
Product Dimensions Physical Size 510 × 457 × 85 mm
Applications Recommended Usage Industrial, Commercial & Outdoor Lighting



Applications (English)

The AKT-TGDRX-500W LED Flood Light is designed for high-power illumination across demanding indoor and outdoor environments, including:

  • Stadiums and sports arenas
  • Industrial factories and warehouses
  • Airports and seaports
  • Parking lots and parking garages
  • Highways, roads, and interchanges
  • Construction sites
  • Building facades and architectural lighting
  • Mining and heavy industrial facilities
  • Billboards and advertising signage
  • Logistics centers and loading bays
  • Security perimeter lighting
  • Shopping malls and commercial complexes
  • Schools and university campuses
  • Public parks and recreational facilities
  • Outdoor event venues
  • Large residential compounds
  • Farms and agricultural facilities
  • Power stations and utility plants

Why Choose AKT Lighting? (English)

Superior Brightness

Delivering up to 40,000 lumens, the AKT-TGDRX-500W provides exceptional illumination for large outdoor spaces while maintaining consistent lighting performance.

Energy Efficient

Advanced LED technology significantly reduces electricity consumption compared to conventional metal halide and halogen floodlights, helping lower operating costs.

Built for Harsh Environments

The IP66-rated enclosure protects against dust, heavy rain, and harsh weather conditions, making it ideal for year-round outdoor use.

Reliable Protection

Designed with an isolated driver, anti-lightning protection, anti-surge technology, and efficient thermal management to ensure stable long-term operation.

Excellent Heat Dissipation

The premium die-cast aluminum housing features a large finned heat sink that rapidly dissipates heat, extending LED lifespan and maintaining performance.

Easy Installation

An adjustable heavy-duty mounting bracket allows flexible installation and precise beam positioning for different lighting applications.

Trusted Quality

AKT Lighting products are manufactured to strict quality standards, providing dependable lighting solutions for commercial, industrial, and municipal projects worldwide.



Warranty (English)

2-Year Manufacturer Warranty

The AKT-TGDRX-500W LED Flood Light is backed by a 2-year limited manufacturer's warranty covering defects in materials and workmanship under normal operating conditions.

The warranty includes:

  • Manufacturing defects
  • LED component defects
  • Driver performance issues
  • Electrical component failures caused by manufacturing faults

The warranty does not cover damage resulting from improper installation, misuse, unauthorized modifications, accidents, natural disasters, voltage abnormalities, or normal wear and tear.
